Specification
| Service | Compatible liquids or gases |
| Wetted Materials | |
| Base | Brass |
| Switch body | Glass reinforced polyester |
| Diaphragm | Polyimide film |
| Temperature Limits | -40 to 248 °F (-40 to 120 °C) |
| Pressure Limits | |
| Set Point Range | 0.5 – 1 PSI ± 0.3 (0.03 – 0.07 bar ± 0.02) |
| Factory Setting* | 1 PSI (0.07 bar) |
| Operating pressure | 150 PSI |
| Proof pressure | 500 PSI |
| Burst pressure | 750 PSI |
| Enclosure Rating | General purpose or with cover: IP65 – Weatherproof |
| Repeatability | ±10% of set-point |
| Switch Type | SPDT snap action |
| Electrical Ratings | |
| Resistive | 15 A at 6 VDC, 8 A at 12 VDC, 4 A at 24 VDC |
| Inductive | 1 A at 120 VAC, 0.5 A at 240 VAC |
| Electrical Connections | #8-32 screw terminals |
| Process Connection | 1/4″ MNPT |
| Mounting Orientation | Switch can be installed in any position |
| Set-point Adjustment | Capable of field-adjustment |
| Agency Approvals | CE |
| Weight | 0.13 lb (0.06 kg) |
